PP Bag Sewing Machine

PP Bag Sewing Machine
PP Bag Sewing Machine
Product Code : ST-502 HD
Product Description

With an aim to satisfy the diverse preferences of clients, we are indulged in manufacturing, exporting and supplying Interlock Sewing Machine. This machine is extensively used in textile industry for seaming, interlocking and hemming stitching over a broad range of light to heavy weight fabrics. In accordance with industry standards, the provided machine is manufactured using the best quality components with the aid of modern methodology under the supervision of our seasoned professionals. Besides, clients can purchase this Interlock Sewing Machine from us at reasonable costs.

Features:

  • Superior performance

  • Longer service life

  • User-friendly interface

  • Automatic internal lubrication

  • Specially designed for heavy weight material such as HDPE, PP, Multiwall Paper and other types of woven sacks.

  • Bobbinless stitching system resulting in production increase.

  • Any type of cotton or synthetic yarn and plastic tape can be used.

  • Easily convertible in single needle machine.

  • Distance between two stitches can be adjusted.

  • Fully automatic lubrication with oil recycling system which ensure long life of machine.

  • Parts are easily available.

Technical Specifications

Max Speed

3,000 R.P.M.

Working Speed

Approx. 2800 R.P.M.
(Depends on Sewing Material)

Seam

Twin-seam, each double thread chain stitch
(2 Needle, 2 Looper, 4 Thread type)

Distance Between Two Needles

6 mm

Stitch Length

11 to 18 stitches per 100 mm (adjustable)

Material Thickness

Upto 8 mm

Kind of Material

All types of Woven Sacks, hessian and multi wall paper bag

Needle Size

DN X 1 # 25.26
(Depends of thickness)

Thread

HDPE or Synthetic / Cotton.

Power Required

1/2 HP Clutch Motor (Single Phase) 2850 R.P.M.

Net Weight

42 Kgs.

Lubrication

Fully Automatic
